Step into a world of refined bass with the Hertz CENTO POWER CP 1.2K This mono amplifier is engineered for high efficiency, reaching an efficiency greater than 89% within a compact, robust aluminum diecast casing. The CP 1.2K is designed to integrate seamlessly into both traditional and modern vehicle setups, thanks to its Universal Speaker Simulator and a wide operating voltage range suitable for electric vehicles. It features advanced noise rejection capabilities to ensure crystal-clear sound quality. With adjustable input levels, a low-pass crossover filter, a bass boost, and a subsonic filter, this amplifier allows for precise customization of your sound, making it an ideal choice for those seeking powerful, immersive bass without compromise.
Channels: 1
Amp class: D
Nominal power supply voltage (fuse): 11 – 15 VDC (2 x 35 A)
Operating power supply voltage: 9 – 18 VDC
Idling current: 0.85 A
Standby current draw: 4.5 uA
Consumption, MIN load impedance (Max Musical Power): 50 A
Remote IN: 4 – 17 VDC (1 mA)
ART – Automatic Remote Turn on/off from SPK-IN (BTL radio only): 1.5 VDC
Efficiency: 89%
Distortion – THD at 100 Hz, 70% Rated Power: 0.03 %
Damping factor at 1 kHz, 1W: 140
Bandwidth at -3 dB: 10Hz – 500Hz
S/N ratio (A-weighted at 1 V Input): 102 dBA
Minimum load impedance:
at 1 Ch: 2 OHM
Adjustable Crossovers: Yes
Output power (RMS) @ 1% THD:
1Ch @ 4 OHM: 650 W x 1
1Ch @ 2 OHM: 1200 W x 1
Total Power: 1200 W
Inputs: Pre-In / Speaker-In
Pre Out: Hi-Pass 50 – 250Hz at 12 dB/Oct.
Pre-In sensitivity: 0.32 – 8 VRMS
Speaker-In sensitivity: 1.6 – 40 VRMS
Sub Ch Lo-Pass: OFF / 50 – 250 Hz at 24 dB/Oct.
Bass Boost 50Hz: 0 – 9 dB
Subsonic Hi-Pass: OFF / 25 Hz at 24 dB/Oct.
Sub Remote Volume Control: -20 – 6 dB (Active on Rear Ch with LPF ON)
CP1.2K: CENTO POWER 1200W 1 CHANNEL AMPLIFIER (CP 1.2K)
