The Venezia V6 (Order Code HMV6) is the first six-channel Hertz marine amplifier, featuring the impressive power of 160 W x 6 (4 Ohm), delivering the output levels needed in the marine environment! Hertz Advanced Class D technology maximizes efficiency and power while minimizing heat and electromagnetic radiation – enhancing sound quality that reaches new highs with Hi-Res certification! High-powered channels with bridging capability. Venezia V6 is engineered and tested for marine applications (UV, salt-fog, vibrations, high/low temperature, thermal shock) and has obtained the IPX2 certification. The Safe-Lock Input, Output, and Power connections streamline installation and enhance durability in the field. The fan less convection cooling system is integrated into the cast heat-sink chassis. The balanced fully-differential input circuitry rejects electromagnetic noise and interference. The powerful and flexible preamp filter options are far beyond most mobile amplifier capabilities. Last but not least, Venezia V6 is fully protected by short-circuit, overload, and thermal protections – with auto-resetting.
Channels: 6 – 5 – 4 – 3
Power supply voltage: 9 – 16 VDC
Idling current (power ON/OFF): 1.8 A / 0.04 mA
Consumption at 1Ohm, 14.4 VDC (Max Musical Power): 75A
Remote In: 7-15 VDC – 1 mA
Distortion – THD (100Hz at 4Ohm): less than 0.06 percent
Bandwidth: 10 – 42 kHz
S/N Ratio (A weighted at 1V): 100 dB
Damping factor (100Hz at 4Ohm): 130
Pre-ln sensitivity: 0.2-5VRMS
Pre-ln impedance: 10 k Ohm
Adjustable Crossovers: Yes
Output Power (RMS) at 14.4 VDC, THD 1 Percent:
6Ch: 160 W x 6 (4 Ohm)
6Ch: 290 W x 6 (2 Ohm)
5Ch: 160 x 4 (4 Ohm) + 580 x 1 (4 Ohm)
5Ch: 290 x 4 (2 Ohm) + 580 x 1 (4 Ohm)
4Ch: 160 x 2 (4 Ohm) + 580 x 2 (4 Ohm)
4Ch: 290 x 2 (2 Ohm) + 580 x 2 (4 Ohm)
3Ch: 580 x 3 (4 Ohm)
Total Power RMS: 1740W
HMV6: MARINE 1740W 6 CHANNEL AMPLIFIER (VENEZIA V6)
